The ventilation system within any greenhouse plays a pivotal role in plant health and crop production. Many new greenhouse growers do not attribute slow growth, poor yields, or problems with pathogens to an inadequate ventilation system. Most gardeners understand the importance of ventilation systems for temperature control, but benefits derived from ventilation systems are multifaceted. Not only are ventilation systems vital to maintaining environmental conditions but they also directly influence a plant’s ability to perform photosynthesis, uptake essential elements, and complete reproductive cycles (pollination). Ventilation systems in greenhouses serve four imperative functions: temperature control, humidity control, CO2/oxygen replacement, and air circulation.
Temperature Control
Greenhouses trap solar radiation thereby raising the temperature in the environment (the greenhouse effect). If this heat is not removed from the environment, it can cause undesirable conditions for plant growth or worse. Ventilation systems, whether natural (passive) or mechanical (powered), serve the basic function of the removal of excess heat.
Humidity Control
Like heat, high concentrations of humidity can become trapped in a greenhouse’s environment. Although some varieties of plants thrive in high humidity conditions, most plants are hindered by the pathogens associated with high humidity levels. Just about every mold, fungus, and mildew thrive in high humidity conditions. Plants transpire moisture that, if not removed, can build up in a greenhouse, raising the humidity levels. It is also very common for the environment within a greenhouse to be affected by the dew point which causes condensation and excess humidity.
CO2 / Oxygen Replacement
Just as humans would run out of oxygen in a poorly ventilated and enclosed area, plants “breathe” CO2 which needs to be replenished in any greenhouse that is not supplementing it artificially. Fresh air drawn into a greenhouse carries with it two important gases needed by plants to carry out some of their most basic functions. During photosynthesis, plants use CO2 which they acquire directly from the air. When CO2 levels decrease the rate of photosynthesis and all other plant functions associated with photosynthesis decrease accordingly. Maintaining an adequate level of fresh air intake guarantees sufficient CO2 levels for plant growth.
We all know plants “breathe” CO2 and expel oxygen, but many people do not know that plants (more specifically plant cells found in the rhizosphere) absorb oxygen in its gaseous form. Although plants create their own oxygen, they still benefit from the replenishment of oxygen found in fresh air. Oxygen is required for the roots to continuously grow and is therefore directly linked to the plant’s ability to uptake nutrients.
Air Circulation
Air circulation, or air movement, within a greenhouse serves many purposes. Proper air circulation creates uniformity in temperature, humidity, CO2, and oxygen within the environment. Plants respond better to environmental consistency and proper air circulation ensures each plant within the greenhouse receives the same atmospheric conditions. Air movement is also our way to simulate the wind in an enclosed environment. Wind strengthens the cell walls of a plant’s stem and directly influences the architectural integrity of plant growth. For many plants wind (or the simulation of) serves an even more integral purpose: pollination. Many vegetable and ornamental plants are pollinated via the wind. Air movement within a greenhouse could be the determining factor as to whether a plant is pollinated and able to complete its reproductive cycle.
Natural (Passive) or Mechanical (Powered) Ventilation Systems
When building a greenhouse or setting up a ventilation system one of the first decisions a gardener must make is whether to use a natural or mechanical ventilation system. A natural ventilation system is a system that has no powered fans but instead relies on wind and thermal buoyancy for air movement. The concept of thermal buoyancy is based on the physical properties of air as air is heated it has the natural tendency to rise. This is a good article to read if you would like to learn more about how thermal buoyancy works in a greenhouse. Most gardeners utilize natural ventilation by implementing a series of ridge (roof) and sidewall vents. As the temperature rises within the greenhouse the hot air rises and escapes through the ridge vents. This process creates a vacuum that draws cooler air into the greenhouse through the sidewall vents located closer to the ground. Wind plays an important role in passive ventilation systems as well. Wind passing over the ridge vents on a greenhouse can create the same vacuum effect and draw fresh air into the sidewall vents. A greenhouse positioned so the prevailing wind blows over the ridge vents will generally be more efficient in terms of natural ventilation.
Mechanical ventilation systems use fans or other mechanical devices to produce adequate airflow and circulation. The main advantage of mechanical systems is a higher level of control. Unlike natural ventilation systems that rely on wind or thermal buoyancy to create air movement, mechanical ventilation systems can be automated to keep a greenhouse’s environmental conditions consistent regardless of the conditions outdoors. Another advantage of mechanical ventilation systems is the ability to have a relatively sealed environment which reduces the entrance of unwanted pests.
Sizing for Natural Ventilation Systems
For some greenhouses, like a hoop house, simply rolling up a portion of the wall to achieve airflow is all that is needed for natural ventilation. However, greenhouses that are built from more rigid materials need to follow a few guidelines to ensure proper ventilation. The most important aspect of natural ventilation for these greenhouses is the size of the ridge (roof) vents and sidewall vents. It is recommended that the total combined ridge vent area should be equivalent to the total combined area of the sidewall vents, and each should equal approximately 20% of the floor area. For example: a 10 ft x 30 ft greenhouse would have a floor area of 300 square feet; 20% of 300 is 60, so a 10 ft x 30 ft greenhouse should have a total area of 60 square feet in ridge vents and 60 square feet in sidewall vents to be properly ventilated naturally.
Sizing and Fan Placement for Mechanical Ventilation Systems
Before sizing mechanical equipment for a greenhouse, it must first be decided if the greenhouse is for seasonal or year-round use. There is a great difference in temperature and humidity from summer to winter and this affects the internal environment of a greenhouse. If you plan on using a greenhouse year-round it would be best to size your equipment for the hotter summer months that require more aggressive ventilation. Just make sure to purchase equipment that is either thermostatically controlled or includes variable speed fans so it can be used throughout the year when less intensive ventilation is needed.
Ventilation Volume Rates for Summer
The generally accepted minimal rate for ventilation during summer months is one air change per minute. Fans are rated for the air volume they move in terms of cubic feet per minute. To determine the fan size needed for a greenhouse we must first figure the greenhouse’s volume in cubic feet. Multiply the length by the width by the height (in feet) of the greenhouse to determine the greenhouse’s volume (in cubic feet). Unfortunately, greenhouses have roof pitches and are not built as perfect cubes or rectangles. This makes determining a greenhouse’s height a little more difficult. If you don’t have a degree in geometry or just want to take the simpler approach, it is acceptable to use a 10-foot height as a constant for most greenhouses. For example, let’s say we are trying to size a mechanical ventilation system for a greenhouse that is 10 ft x 30 ft and we decide to use the 10 ft constant as the height. By multiplying the length (30 ft) by the width (10 ft) by the height (10 ft constant) we find the greenhouse’s volume: 30 ft x 10 ft x 10 ft = 3,000 cubic feet. We want a fan that can exchange that volume in one minute so we would need a fan with a rating of 3,000 cubic feet per minute or greater.
Ventilation Volume Rates for Winter
Ventilation in wintertime is rarely used for temperature control. In fact, most greenhouses used during winter months require heat to be supplemented by additional mechanical equipment. A ventilation system’s biggest job during winter months is humidity control. The large temperature variance between the inside and outside of a greenhouse causes condensation that will raise humidity levels significantly. A rate of ventilation must be calculated to remove excess humidity but also keep a balance in temperature to help keep heating requirements to a minimum. It is recommended to target three air changes per hour,or one air change every 20 minutes. In other words, the requirement for a fan load in winter months is one twentieth of that in summer months.
Ventilation Volume Rates for Fall/Spring
Ventilation volume requirements for fall and spring will be somewhere between the ventilation required to remove the excessive heat in the summer and the requirements for humidity control in winter. Temperature and humidity are extremely variable during fall and spring so ventilation systems with thermostatically controlled fans or automated atmospheric controllers may be more efficient and effective.
Fan Placement
Heat rises so it is generally advantageous to place exhaust fans toward the top of a greenhouse. If possible, place intake vents or fans lower to the ground, preferably on the opposite side of the greenhouse than the exhaust. This will create a path of airflow across the entire greenhouse which makes a ventilation system operate more efficiently.
Fresh Air Movement
Oscillating fans within a greenhouse are a great tool to help create air movement and uniformity within a greenhouse. Another tool that can be used to better distribute fresh air in a greenhouse is perforated polyethylene tubes. Connected to intake fans these tubes distribute fresh air evenly throughout the greenhouse and directly to the plants themselves.
The diverse roles played by ventilation systems in greenhouses directly influence basic plant functions like photosynthesis, affect the way our flowers bloom and our plants are pollinated. Calculating required exhaust volumes, sizing vent areas, and implementing devices to better unify the atmospheric conditions within a greenhouse are all ways to assess or design a ventilation system to ensure optimal performance.
Eric Hopper resides in Michigan’s beautiful Upper Peninsula where he enjoys gardening and pursuing sustainability.
